Core Overview
The UP2400-6S is a high-performance charging solution designed for professional fields such as drones, film production, fire rescue, surveying, and agricultural plant protection. Its core design goal is "efficiency multiplication." Through an internal dual-power architecture, it achieves truly independent four-channel simultaneous high-current (up to 25A) balance charging, which can increase multi-battery pack charging efficiency by up to 50%. It integrates efficient charging, powerful battery balance repair, and intelligent maintenance, making it an ideal choice for team operations and high-intensity applications.
Core Technology Advantages
Efficiency Multiplied, Four Truly Independent Channels
Utilizes dual independent power modules internally, supporting four channels to perform balance charging simultaneously at up to 25A current. Compared to traditional dual-channel chargers, charging efficiency can be increased by up to 50%, significantly reducing equipment preparation time.
1.5A/Cell Powerful Balancing, Battery Repair
Industry-leading high balancing current quickly corrects cell voltage differences within battery packs. It has a significant repair and maintenance effect on batteries with degraded performance or abnormal voltage differences, effectively extending the overall lifespan of the battery pack.
Wide Compatibility, One Device for Multiple Uses
Fully compatible with standard lithium batteries (LiPo, 4.20V/cell) and high-voltage lithium batteries (LiHV, 4.35V/cell), supporting 2-6S batteries. Features a dedicated independent transmitter battery charging port, catering to the maintenance of both main equipment and its transmitter.
Usage Recommendations
- Power Supply Assurance: The device's total power is as high as 2400W. Always connect it to a power source with sufficient capacity (recommended 16A dedicated wall outlet) and ensure good ventilation around the device to guarantee stable operation and safety.
- Maximize Efficiency: The core value lies in the four completely independent channels. Make full use of this feature to simultaneously charge or maintain batteries of different types, specifications, and charge levels to achieve maximum efficiency.
- Battery Health Management:
- Regular Balancing: Even if the battery shows no warning, it is recommended to regularly use the "Balance Charge" mode to maintain cell consistency using its high balancing current.
- Mandatory Storage: After operations, for batteries not in immediate use, always use the "Storage" mode to charge/discharge the battery to a safe voltage. This is a key habit for protecting battery assets.
- Note the Dedicated Port: The independent 2-3S transmitter charging port only supports small batteries and must not be used with the main channels.
Product Specifications
| Item | Specifications |
|---|---|
| Input Voltage | AC 110V / 220V Auto-Adaptive |
| Total Charging Power | 2400W (600W × 4 channels) |
| Discharge Power | 140W (35W × 4 channels) |
| Max Current per Channel | 25A |
| Balance Current | 1.5A / Cell |
| Supported Battery Types | LiPo (Standard Lithium), LiHV (High Voltage Lithium) |
| Supported Cell Count (S) | 2-6S (Main Channels); 2-3S (Dedicated Transmitter Port) |
| Charging Modes | Balance Charging, Storage (Maintenance) Mode |
| Display Interface | 3.2-inch Chinese HD Color Screen |
| Product Dimensions | 270 × 337 × 150 mm |
| Product Weight | 8.5 kg |
Frequently Asked Questions (FAQ)
Q: Can the four channels charge different types (LiPo/LiHV) or different cell counts (e.g., 2S and 6S) of batteries simultaneously?
A: Absolutely. This is the core advantage of this product. The four channels are completely independent, allowing separate settings for battery type, cell count, and charging current without interference, enabling truly flexible and efficient charging.
Q: What does the advertised "battery repair" function specifically refer to? How is it operated?
A: It mainly refers to its powerful balance repair capability. When a battery pack develops cell voltage imbalance (voltage difference) due to use, simply use the "Balance Charge" mode of this unit. Its high balancing current of up to 1.5A/cell quickly equalizes the voltage of each cell, restoring the consistency of the battery pack, thereby "repairing" performance degradation or charging issues caused by excessive voltage difference. The operation is the same as a normal balance charge.
Q: How to charge transmitter batteries?
A: Please use the dedicated 2-3S transmitter battery charging port on the side of the unit. Note: This port can only charge one transmitter battery at a time, and the charging current is fixed at a safe low current. It is strictly prohibited to use it for main batteries or simultaneously with other main channels.
